Overview
| Place of Origin | Guangdong, China | Brand Name | Slocable |
| Model Number | PEDSC100R/120R-DB32 | Type | DC Isolator Switch |
| Application | Power, Waterproof Case | Item | Waterproof Distribution Board DC Isolator |
| Rated Voltage | 1500V | Rated Current | 32A |
| Pole | 2P/4P/6P/8P | Connection | Stable Working Status |
| Certificate | TUV, CE, CB, SAA, CCC | Operation Temperature | -40℃~ +70℃ |
| Protection Degree | IP66 Waterproof | Mounting | Din Rail Mounting |
Product Description
Advantages of Waterproof Enclosure DC Isolator Switch:
- Non-polarity DC Isolator Switch.
- Pannel Mounting, Distribution Board, Door Clutch Mounting or Plastic Enclosure optional.
- Compact structure and modular design, levels with different Poles from 2 to 8 are available.
- Parallel connections design, more big bore diameter makes connection fastness and flexibility.
- Fast switching structure, arcing time normally occurs less than 3ms.
- Dynamic sealing design and world class sealing materials guarantee an IP66 protection rate.
- UL94V-0 standard flame resistant materials , the DC Isolator Switch can be full loading operation at temperatures -40 ℃ ~+70℃.
- DC 1500V insulation voltage design, with TUV, CE, SAA, DC-PV1 and DC-PV2 certifications.
